This machine adopts up and down stage separating drive. Up stage adopts single shaft mixing. Boxes are welded using steel plate. Machine¡¯s big pressure is suitable for producing high rate hole brick with materials like shale,gangue,clay and so on.
|
Specification model
|
Capacity
(Standard bricks/H)
|
Power(KW)
|
Vacuum degree (MPa)
|
Max extrusion pressure ( MPa)
|
Size (mm)
|
|
HD90-40
|
16000-26000
|
280+132
|
¡Ü-0.092
|
4.0
|
9600¡Á3200¡Á3500
|
|
HD75-40
|
13000-22000
|
250+110
|
¡Ü-0.092
|
4.0
|
9400¡Á3100¡Á3300
|
|
HD60
|
10000-18000
|
200+90
|
¡Ü-0.092
|
4.0
|
8800¡Á2900¡Á2900
|
|
HD50
|
6800-13000
|
132+55
|
¡Ü-0.092
|
4.0
|
7400¡Á2600¡Á2600
|
